YPS Single-Shaft Shredder (swing-arm)
Versatile single shaft shredder with 800mm cutting width for processing various plastic waste including pipes, profiles, films, and containers.
Product Specifications
- Capacity 300-1000 kg/h
- Material PP, PE, LDPE, HDPE Films
- Power 150-300 kW
- Pellet Size 2-5 mm
- Warranty 1 Year
Product Description
Compared with basic SS single rotor shredder, YPS series of shredders optimizes design. With a hydraulic swing arm to force material toward it’s bigger rotor for consistent feeding.
YPS series of single-shaft shredder: higher capacity, Swinging pusher.
| Model | YPS850 | YPS1050 | YPS1250 | YPS1450 |
| Motor power | 55kw | 75kw | 90kw | 110kw |
| Hydraulic Power | 5.5kw | 5.5kw | 7.5kw | 7.5kw |
| Rotor length | 850mm | 1050mm | 1250mm | 1450mm |
| Rotor diameter | ⌀460 | ⌀460 | ⌀460 | ⌀480 |
| Rotary speed | 74rpm | |||
| rotary knives | 60 pcs. | 75 pcs. | 88 pcs. | 96 pcs. |
| Electrical control cabinet | PLC control: Siemens | |||
| Capacity
(for PE films) |
500-600kg/h | 800-1000kg/h | 1000-1500kg/h | 1500-2000kg/h |
