LPS single-rotor shredder for long pipes
For long plastic pipes—whether large or small in diamet […]
Product Specifications
- Capacity 300-1000 kg/h
- Material PP, PE, LDPE, HDPE Films
- Power 150-300 kW
- Pellet Size 2-5 mm
- Warranty 1 Year
Product Description
For long plastic pipes—whether large or small in diameter—they can be nested together, or if cutting them short is not desired, this shredder can process them as well.
LPS series of single-shaft shredder: particularly for big and long pipes.
| Model | LPS800 | LPS1200 |
| Motor power | 37kw*2 | 45kw*3 |
| Hydraulic Power | 15kw | 5.5kw |
| Rotor length | 800mm | 1200mm |
| Rotor diameter | ⌀800 | ⌀1200 |
| Rotary speed | 40rpm | |
| rotary knives | 60 pcs. | 168 pcs. |
| Maximum pipe allowed | ⌀630 | ⌀1100 |
| Electrical control cabinet | PLC control: Siemens | |
| Capacity
(for PE pipes) |
800-1200kg/h | 1500-2000kg/h |
